This is a non-stocked item, please call +44 (0)1482 601030 or email sales@flowstar.co.uk for price and availability.
Specification
Sizes: 15mm to 150mm
Connections: Screwed BSPP Female (upto 50mm), Screwed NPT Female (upto 50mm) or Flanged (All Sizes)
Materials: Cast Iron, Carbon Steel, Bronze & Stainless Steel
Medium: Steam, Water, Air & Gases
Inlet Pressure (Max): 35 Barg (Cold)
Outlet Pressure Range: 0.3 to 12.5 Barg (Standard Top) or 25 Barg (High Pressure Top)
Cv Range:
Temperature: 220 degC Max
Notes: (a) Pressure Control: plus or minus 1% (b) Full bore and Low Flow Trims (c) Minimum Pressure Drop: 1.5 Barg
