This is a stock item. Order by 5pm Monday to Thursday and 4.30pm Friday for same day despatch. Specification Sizes: 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1.1/2" (DN40) and 2" (DN50)
Connections: Flanged PN40 Inlet x Flanged PN40 Outlet
Materials: Stainless Steel Body & Bonnet
Disc: FKM
Seals: FKM
Medium: Suitable for aggressive water and other aggressive liquids, compressed air, nitrogen and gases. Not suitable for steam.
Inlet Pressure (Max): 40 Barg
Outlet Pressure Range: 0.5 to 9 Barg
Kvs Range: 2.9 to 13
Temperature: 190 degC Max
Approvals: PED 97/23/CE category I
Notes: We have a sizing calculator in the TECHNICAL INFO section on the menu bar above.
