This is a stock item. Order by 5pm Monday to Thursday and 4.30pm Friday for same day despatch. Specification Sizes: 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1.1/4" (DN32), 1.1/2" (DN40) and 2" (DN50)
Connections: Female BSP Inlet x Female BSP Outlet
Materials: Body - Gunmetal
Bonnet: Brass (DN15 to DN32) / Cast Iron (DN40 to DN50)
Joints & Seals: Diaphragm: NBR, Seals: NBR
Medium: Gases & Liquids i.e. Water (suitable for drinking water), neutral non-viscous fluids, compressed air, nitrogen, non-combustible gases. Not suitable for steam.
Inlet Pressure (Max): 40 Barg (1/2" to 1.1/4") 25 Barg (1.1/2" & 2")
Outlet Pressure Range: 0.5 to 9 Barg
Temperature: -20 to +100 degC
Approvals: PED 97/23/CE category I
Notes: (a) Built in gauge ports & Integral Strainer (b) Minimum pressure drop between inlet and outlet: 1 Barg (c) We have a sizing calculator in the TECHNICAL INFO section on the menu bar above.
