This is a stock item. Order by 5pm Monday to Thursday and 4.30pm Friday for same day despatch.SpecificationSizes: 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20)
Connections: Female BSP Inlet x Female BSP Outlet
Materials: Gunmetal Body / Bonnet Brass
Disk: Regulating Piston: Brass
Joints & Seals: Seals: NBR
Medium: Gases & Liquids i.e. Water (suitable for drinking water), neutral non-viscous fluids, compressed air, nitrogen, non-combustible gases. Not suitable for steam.
Inlet Pressure (Max): 60 Barg
Outlet Pressure Range: 20 to 45 Barg
Cv Range:
Temperature: 100 degC Max
Approvals: PED 97/23/CE category I
Notes: Highest Reduction Ratio: 3:1. We have a sizing calculator in the TECHNICAL INFO section on the menu bar above.
